APC by Schneider Electric NetShelter AP8858 PDU

  • Part: 1000533
  • Model: AP8858
$1,443.20

Availability

In Stock

APC Metered Rack Power Distribution Units (PDUs) provide active metering to enable energy optimization and circuit protection. User-defined alarm thresholds mitigate risk with real-time local and remote alerts to warn of potential circuit overloads. Metered Rack PDUs provide power utilization data to allow Data Center Managers to make informed decisions on load balancing and right sizing IT environments to lower total cost of ownership. Metered Rack PDUs include real power monitoring, a temperature/humidity sensor port, locking IEC receptacles, and ultra low profile circuit breakers. Users can access and configure Metered Rack PDUs through secure Web, SNMP, or Telnet Interfaces which are complimented by APC Centralized Management platforms using InfraStruxure Central, Operations, Capacity, and Energy Efficiency.

  • General Information
    • Manufacturer
    • Schneider Electric SA
    • Manufacturer Website Address
    • http://www.schneider-electric.com.au
    • Brand Name
    • APC by Schneider Electric
    • Product Line
    • NetShelter
    • Product Series
    • Metered
    • Product Type
    • PDU
  • Warranty
    • Limited Warranty
    • 2 Year

  • Technical Information
    • Plug/Connector Type
    • IEC 60320 C20
    • Receptacle Type
    • IEC 60320 C13
    • IEC 60320 C19
    • Receptacle Detail
    • 18 x IEC 60320 C13
    • 2 x IEC 60320 C19
  • Power Description
    • Input Voltage
    • 200 V
    • 208 V
    • 230 V
    • Output Voltage
    • 100 V AC
    • 200 V AC
    • 208 V AC
    • 230 V AC
  • Management
    • Management
    • Protocols:

      • SNMP
      • Telnet
  • Physical Characteristics
    • Mount Type
    • Rack-mountable
    • Rack Height
    • 0U
    • Height
    • 902 mm
    • Width
    • 56 mm
    • Depth
    • 44 mm
    • Weight (Approximate)
    • 2.93 kg
  • Miscellaneous
    • Package Contents
      • Metered Rack AP8858 20-Outlets PDU
      • Installation Guide
      • Rack Mounting Brackets
      • Safety Guide
      • Sample Locking IEC Power Cord
      • Serial Cable Configuration
    • Environmentally Friendly
    • Yes
    • Green Premium
    • Yes
    • Optimized Energy Efficiency
    • Yes
    • Product Take Back Program
    • Yes
    • REACH free of SVHC
    • No
    • Mercury Free
    • Yes
    • Lead Free
    • Yes
    • RoHS Exemption Information
    • https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=AP8858_ROHS_DECLARATION&p_FileName=AP8858KIT_ROHS_DECLARATION_US.pdf
    • REACH Declaration URL
    • https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=65033442&lang=en-us
    • EU RoHS Declaration URL
    • https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=65033442&lang=en-us
    • Environmental Profile Availability
    • https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1712014_EN
    • End of Life Manual Availability
    • https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1712014_EN
