DeepCool PQ1000G
Technical Spec
Total Output 1000W
Type ATX12V V3.1
Product Dimensions 150×140×86mm (W x L x H)
Efficiency certification 80Plus Gold/Cybenetics PLATINUM/PPLP Gold
Fan Size 120×120×25mm (W x L x H)
Fan Bearing FDB (Fluid Dynamic Bearing)
Topology Active PFC + Half Bridge SRC LLC + DC to DC
Capacitors Full Japanese Electrolytic Capacitors
Power Good Signal 100-150ms
Hold Up Time ≥16ms Full load
Efficiency ≥90% Under Typical Load(50% Loading)
Protection OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO
Operation Temperature 0-40°C
Regulatory EAC
Erp Regulation ErP 2013
Environment Protection EAC
MTBF 100,000 Hours
