Vertiv™ VE Rack
The Vertiv VE Rack is an innovative enclosure system that integrates your computing hardware, power management technologies and peripherals in data centers and computer rooms. It offers superior design and flexibility, allowing optimal data center performance and easy installation.
FREE STANDING SERVER RACK
The VertivVE Series Rack provides cooling, power distribution, cable management, and environmental monitoring infrastructure for application in IT environment.
- Perforated doors for optimal front-to-rear air flow up to 75%
- Tool-less mounting slots for vertical PDUs
- Loading capacity of up to 1600 kgs
VertivVE rack is the ultimate solution designed and engineered for demanding data center environment.
To achieve optimum versatility within the server rack, users can set multiple depths throughout the rack by adjustable 19-inch mounting rails mounted on heavy duty side supports.
Horizontally divided side panels provide ease of access and convenient post-installation maintenance.
Over 75% perforations on front and rear door enable optimum air flow within the rack.
Flat-pack option enables savings up to 60% in the transport cost and warehouse space.
Vertiv™ VE Rack Features:
- Strong and durable nine-folded solid frame profile which can hold a static load of up to 1,600 kg
- 75% open high perforated doors for optimal air flow
- Convenient tool-less installation of cable and air flow management
- Fast deployment leveling feet
- Heavy duty caster wheels for easy movement
You need a rack ready to go
Get what you need, when you need it:
- Enclosure height of 42U and 48U
- Width of 600 mm or 800 mm and Depth of 1100/1200 mm
- Other dimensions available on request
- Side panels
- Air flow management
- Cable management options
- Mounting accessories
- Standard Color RAL 7021 (Optional Color RAL 7035)
Excellent Rack Cooling Efficiency
- Optimal heat management with 75% perforation rate for both front and rear doors
- Optional blanking panels for air flow are available
Enhanced Rack Installation Space Efficiency
- Solid steel frame with installation slots
- Rack static load capacity of 1,600 kg
Enhanced Rack System Applicability In Data Centers
- Accessories available for cabling and air flow management
- Optional features for specific requirements in data centers available
Increased Convenience In Installation And Maintenance
- Tool-less design for cable, air flow management, and PDU mounting for flexible and quick installation
- Low profile casters preconfigured for easy deployment and mobility
- Self-leveling feet for easy installation
Increased Rack Adaptability and Expansibility
- Integral part of the total data center solution of Vertiv
- Highly adaptable and flexible to integrate power, cooling, and monitoring equipment
- Containment solutions available
- Supports a variety of rackbased SmartAisle (cold aisle / hot aisle) solutions
- General Information
- Manufacturer
- Vertiv
- Manufacturer Website Address
- http://www.vertiv.com/
- Brand Name
- VERTIV
- Product Series
- VE
- Product Type
- Rack Cabinet
- Technical Information
- Rack Type
- Enclosed Cabinet
- Application/Usage
- Server
- PDU
- Features
- Lockable Side Panel
- Perforated Door
- Cable Management
- Adjustable Mounting Rails
- Leveling Feet
- Casters
- Physical Characteristics
- Form Factor
- Floor Standing
- Product Color
- Black Gray
- Product Material
- Steel
- Mesh
- Static/Stationary Weight Capacity
- 1600 kg
- Width
- 600 mm
- Depth
- 1100 mm
- Rack Height
- 42U
- Rack Width
- 482.60 mm
- Miscellaneous
- Package Contents
- VE Rack Cabinet with Side Panels, Build up with Pallet
- Single Flat Front Mesh Door
- Double Flat Rear Mesh Doors
- Roof Top with Cable Entry Plates
- 2 x Pairs of Side Panels, Top and Bottom
- 4 x (19") EIA-310 Vertical Mounting Rails
- 4 x Fast Deploying Leveling Feet and 4 Casters
- 2 x Vertical PDU / Cable Management Tray Ready for Dual PDU Mounting
- 50 x Sets of Captive M6 Nuts and M6 Screws
- 1 x Set of Integrated Baying Kit
- Open Bottom Area (optional cover)
- Assembly Required
- No
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
